QDX-S  Stainless steel barrel submersible electric pump

product description:

The motor of Q(D)X-S series submersible electric pump (hereinafter referred to as electric pump) is located in the upper part of the electric pump, which is single-phase or three-phase asynchronous motor. The water pump is located in the lower part of the motor, adopting centrifugal impeller and worm shell structure. The dynamic seal between the water pump and the motor adopts double face mechanical seal and skeleton oil seal. The static seals at the fixed stops are made of oil-resistant rubber "O" sealing rings.
The motor of this product is made of stainless steel for better corrosion resistance.

Product Usage:

It is suitable for pumping water from wells in rural areas, irrigation and drainage of farmland, watering of gardens, spraying, water for family life, and can also be used for removing water from industry, water supply and drainage of building construction, and aquaculture and other places.

Conditions of Use:

1. Medium temperature does not exceed 40°C.
2. medium pH value in the range of 6.5 ~ 8.5.
3. the medium contains solid impurities volume ratio of not more than 0.1%, particle size of not more than 0.2mm.
4. the power frequency is 50Hz, the voltage is single-phase AC 220V, three-phase AC 380V, the voltage fluctuation range is 0.9~1.1 times of the rated value.
5. Diving depth is not more than 5m.
