YCQY  Permanent magnet variable frequency submersible pump

Product description:

Our company produces YCQY permanent magnetic submersible electric pump (hereinafter referred to as electric pump). It adopts ultra-high efficiency, rare-earth permanent magnet synchronous motor, advanced mechanical seal, and the impeller is directly installed on the main shaft of the motor, so it has high efficiency, low power consumption, compact structure, light weight, and convenient installation and maintenance. The whole pump casing, shaft, mechanical seal bullet, screws are made of 304 stainless steel, the impeller is made of precision casting 304 stainless steel, can be used in corrosive media.

Product Usage:

This series of products adopt permanent magnet motor. With small volume, high efficiency, electricity saving, light weight and easy to move. Widely used in aquaculture, farm irrigation, garden watering, well watering, water tower water supply, industrial water removal, building water supply and drainage.

Conditions of Use:

The electric pump should be able to work continuously under the following operating conditions.
1、Water quality is clear water, there should be no dimension or solid particles
2、Medium temperature:≤0°C≤50°C
3, the surrounding ambient temperature: not more than +45 ° C
4、Power frequency is 50HZ, voltage single-phase 220V, three-phase 380V, (voltage frequency can be customized) voltage fluctuation range of 10% of the rated value.
